The liquid crystal display module and the liquid crystal module refer to components for assembling a liquid crystal display device, a connecting member, a peripheral circuit for controlling and driving, a PCB circuit board, a backlight, and a structural member.
The technical specifications of the liquid crystal display module (LCM) currently available from Xin Hongtai are as follows:
The number of dot matrix is: 122*32, 128*64, 160*32, 256*32, 192*64, 240*64, 160*128, 240*128, 256*128, 320*240, 640*200, etc. Product
Working temperature: normal temperature 0 ~ +50 ° C, wide temperature -20 ~ +70 ° C, ultra wide temperature -30 ~ + 80 ° C;
Interface type: 3-wire or 4-wire SPI serial port, 8-bit or 16-bit MCU parallel port, I2C, RS232 or RS485, USB interface;
Display mode: black on white, black on yellow and green, black on blue, white on blue, white on black, custom silk screen, etc.
| Checklist | Model | Product type | Show contents | Product map |
Outline size (mm) |
Horizon (mm) |
Display size mm/inch |
Point spacing mm |
Visual angle | Brightness | Pin | Interface | Instructions | Working temperature | Voltage | Driver chip model |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 3.0-inch graphic LCD module|128x64 graphic display LCD module | STN+ yellow-green backlight | 5.0V | ST7565R controller HTM12864-7-11Y-A5P | Graphic LCD Module | 128x64 |
|
95.0x56.7x13.5 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | YG | FPC-9PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0-inch gray background blue character graphic LCD module | 128x64 graphic display LCD module HTM12864-7-11Y-A5P | Graphic LCD Module | 128x64 |
|
95.0x56.7x13.5 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | FPC-9PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0-inch gray background blue character graphic LCD module | 128x64 graphic display LCD module | SPI interface HTM12864-7-11W-A5P | Graphic LCD Module | 128x64 |
|
95.0x56.7x13.5 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | FPC-9PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3.0-inch black 128x64 graphic display LCD module|ST7565R | DFSTN negative display HTM12864-7-41W-A5P | Graphic LCD Module | 128x64 |
|
95.0x56.7x13.5 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | FPC-9PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3" Blue Background White Font 128x64 Graphic LCD Display Module | ST7565R | SPI for Arduino HTM12864-7-25W-A5P | Graphic LCD Module | 128x64 |
|
95.0x56.7x13.5 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | FPC-9PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 3 inch graphic LCD module |12864 graphic display|128x64 graphic LCD LCD module HTM12864-7-31W | Graphic LCD Module | 128x64 |
|
95.0x56.7x13.5 | 65.6x38 | 60.775x32.935 | 0.475x0.515 | 6H | white | FPC-9PIN | SPI | Anti-static ESD 8KV | -20~70℃ | 5.0V | ST7565R | |
| 1.7-inch industrial LCD display/128x64 graphic dot matrix LCD module/red, green and blue backlight/FSTN+transmissive polarizer HTM12864C02-35S-A3P | Graphic LCD Module | 128x64 |
|
40.6x32.2x11.0 | 37.0x23.3 | 33.26x20.48 | 0.26x0.32 | 6H | R/G/B | FFC-18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 1.7-inch LCD128 x 64 industrial control graphic LCD screen/LCM128x64 graphic dot matrix LCD module/Arduino HTM12864C02-11Y-A3P | Graphic LCD Module | 128x64 |
|
40.6x32.2x11.0 | 37.0x23.3 | 33.26x20.48 | 0.26x0.32 | 6H | YG | FFC-18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | +3.3V | ST7565R | |
| 1.7-inch LCD12864 LCD screen/LCM128x64 graphic dot matrix module/white text on black background/MCU interface HTM12864C02-41W-A3P | Graphic LCD Module | 128x64 |
|
40.6x32.2x11.0 | 37.0x23.3 | 33.26x20.48 | 0.26x0.32 | 6H | white | FFC-18PIN | MCU | Anti-static ESD 8KV | -20~70℃ | 3.3V | ST7565R | |
| 1.7 inch 128X64 graphic LCD module | STN + LCD display | With white side backlight | ST7565R controller HTM12864C02-11W-A3P | Graphic LCD Module | 128x64 |
|
40.6x32.2x11.0 | 37.0x23.3 | 33.26x20.48 | 0.26x0.32 | 6H | white | FFC-18PIN | MCU | 防靜電ESD 8KV | -20~70℃ | +3.3V | ST7565R |
